4x2 Foton 220hp Cummins Engine 12 Ton Tow Truck Towing Vehicle

Product Categories
Hubei iTruck Import and Export Trading Co., Ltd
Contact Now

4x2 Foton 220hp Cummins Engine 12 Ton Tow Truck Towing Vehicle

  • 1
  • 2

Brand Name : Foton

Place of Origin : Hubei, China

MOQ : 1

Supply Ability : 5 unit/month

Delivery Time : 85 days

Packaging Details : Nude, covered with protection film

Product name : Integrated Wrecker Truck

Condition : New

Drive type : 4x2 driving

Main Winch : 8 tons/10 tons, 2 pcs

Auxiliary Winch : Optional

Underlift : G70, 3 sections

Boom : G70, 2 sections

Remote Control : Wireless

Hydraulic : DOT certified

Warranty : 3 Year

Contact Now

4X2 FOTON 220HP CUMMINS ENGINE 12 TONS INTEGRATED TOW TRUCK
Product Description

The medium duty integrated series have different capacities from 8 tons to 18 tons.

ENGINEERED FOR STRENGTH AND DURABILITY

The 12 ton Integrated Medium Duty wrecker with a 17,800 lb. rated underlift and a modern, steel body that is maximized for available storage and deck space.

The truck brand options also available with ISUZU, Dongfeng, HOWO, JAC, FOTON, JMC, FAW, SHACMAN, IVECO, etc.

With Euro 2, Euro 3, Euro 5, Euro 6 emission.

With RHD, LHD.

With 4x2, 4x4, 6x4, 6x6, 8x4, 8x8.

Other special requirements you want.

Main Features
1. 8 Tons / 17,800 lbs. Planetary Winch, 2 Pcs. Total 16 Tons / 35,600 lbs.
2. 8 Tons / 17,800 lbs. Underlift Capacity, Tow Rate At Least 16 Tons / 35,600 lbs.
3. Spacious Tool Compartments
4. Multi-Positional Rear Jacks
5. Optional Remote Control
6. Available Low Profile Tow Bar
Truck Specs
12 Tons Foton Wrecker Truck
Overview
Name 12 Tons Foton Wrecker Truck
Dimension(LxWxH) 8250x2250x2655(mm)
Total Mass 16510Kg
Rated Payload 12000Kg
Kerb Weight 4510Kg
Passenger 3
Approach/Departure Angle 30/23
The Parameters of Chassis 　
Manufacture/Model Foton
Driving Type 4*2 LHD/RHD
Wheel Base 5150 mm
Gearbox FAST 8JS85T, eight speed forward and two reverse, manual
Front/Rear Track 1914/1800(mm)
Tyre 10.00R20
The Number of Tyre 6+1(spare tyre)
Front/Rear Suspension 1250/2320(mm)
Leaf Spring Number 4+3
Fuel Tank 260L Aliminum
Power Steer, AC, Air Brake, MP3, ABS, etc Equipped
The Paremeters of Engine
Manufacturer/Model Cummins/ISF4.5 210
Rated Power 210hp
Fuel Type Diesel oil
Displacement/Capacity 4460ml
Emission Standard Euro 5
Cylinder In-line/4/intercooling/turbo charge/Bosch common rail/pressure direct injection
Max. torque 760N.m
Velocity 2300rpm
Body Specs
12 Tons Wrecker Body Specs
No. Item Content Details Unit
1 Name 12 Tons Wrecker Body
2 Winches 2×8 Tons Main Winches

Side puller (8 tons) is optional,

extra USD2,000
3 Underlift Underlift G70 material, 3 stage
4 Boom Boom G70 material, 2 stage, hexagon
5 Legs Rear Hydraulic rear supporting legs

Front support legs are optional.

Extra USD1,500
6 Frame LED Lights Frame, full size
7 Toolbox On Both Sides

Carbon steel Q345R, with

stainless steel handles

Aluminum tool box optional,

extra USD3,000
8 Hook-Ups Air and Electrical Hook-Ups 12V or 24V
9 Control Remote Wireless Control

Optional button remote control.

Extra USD1,000

Optional Joystick type remote control,

English Display Extra USD3,000
Hand Manual Control

On Lift and Right Sides,

English

Indication
10 Hydraulic Parts Hydraulic Pump
Hydraulic Hose
Hydraulic Connector
Valves Italy Hydrocontrol
Cylinders
11 Attachments 5 Sets of Forks 4 sets for axle, 1 set for suspension
U shape tyres holder 1 set
Safety Chains 2 pcs
12 Painting and Indication Electrophoresis Painting Toolbox EP painting

Subframe with boom and underlift

EP painting extra USD1,200
Surface Painting Epoxy Resin
Indication English Indication and Marks
Specifications
1 Underlift Retracted Lifting Capacity 8000 kg
Retracted Length 1505 mm
Extended Lifting Capacity 3500 kg
Extended Length 2760 mm
Undelift Tilt -10 °
Towing Capacity 16-24 ton
2 Boom Retracted Lifting Capacity (45°) 12 ton
Extended Lifting Capacity (45°) 5.5 ton
3 Main Winches Quantity 2 pcs
Pulling Power 8 ton
Type Planetary
Steel Wire Length 45 m
Steel Wire Diameter 16 mm
4x2 Foton 220hp Cummins Engine 12 Ton Tow Truck Towing Vehicle4x2 Foton 220hp Cummins Engine 12 Ton Tow Truck Towing Vehicle
